 Description : |
Mini Loader is a new mini type multifunctional machine with advanced performance. With compact structure, agile movement, flexible operation, high efficient work and mighty function, HRL300 Mini Loader is competent for the work in narrow space or situation with frequently changing task, such as municipal projects, workshop, warehouse, dock, ship deck and ship cabin, etc. It can be competent for shoveling, lifting, excavating, drilling, snatching, clearing work with different attachments. |
Specification:
| Details of mini skid steer loader
Mini tractor backhoe loader /mini loader is for sale by direct manufacture with lower price,high quality and good after-sale service Brief Introduction Style: wheel or crawl can be choosed. Transmission: hydraulic transmission Control system: hydraulic system Steering:360¡ã steering Driven: 4 wheels ,2 drivers, 4 drivers can be choosed Overall dimension:2206*1150*1233mm (with 1 standard bucket) Future: Mini tractor backhoe loader / mini loader Motor: with an imported engine,Briggs &Stratton gasoline engine from USA, (23HP) ,also can adopt Chinese diesel engine(22HP) Pump: China or Italy pump Valve: Italy hydraulic valve, Italy technology, domestic assembly Rated loading:300kg With engineering tires, rubber track Bucket capacity:0.15M3 Gasoline tank capacity:25L,Hydraulic tank capacity:25L Travelling speed:0-5.5km/ |
 |
Standard layout: wheel loader,with one stardard bucket,0.15 m3 Detail Photos: |
 |
 |
|
| Standard layout (wheel loader,with a bucket) | with lawn mower same as a tractor |
 |
 |
 |
| Be crawler with tracked wheel | with grappler | with series of auger |
 |
 |
 |
| Mini excavator or digger | with rotary tiller | with fork shovel |
 |
 |
|
| The attachment | The detaill of structure |
Packing Delivery & Payment |
 |
 |
 |
 |
|
| A meter panel operated easily | by steel frame (1 set) |
| A convenient pedal plate Question: Q1. What¡¯s type of engine? A: Briggs&Stratton Gasoline Engine imported from USA Q2.What¡¯s kind of tire or track? A:Herringbone Engineering Tyres, Rubber tracked wheel Q3.What¡¯s factors of affecting the price? A: 1.Standard equipments (Imported engine , China mortor,valve, pump),good price 2. High configuration (imported engine,Italy servo control,china mortor,pump), high price Packing photo |
Warranty£º 12 months Oil type£ºEither Gasoline or Diesel Moving way: Track or wheel Certification: CE Hose power£º23HP Bucket£º0.15CBM Dimension (long*wild*high):2210*1160*1250 Packing detail: steel pallet ply-wood cover Delivery detail: about 15 days |
| Model Item | HRL300 | |||
| Engine | Rated Power(Kw) |
23Hp |
||
Rotating speed(rpm) |
3600 |
|||
Noise (dB) |
|
|||
hydraulic System |
Pressure(Mpa) |
17 |
||
| Cycle Time (s) | Raise |
Dump |
Lower |
|
4.27 |
1.34 |
3.31 |
||
Performance |
Operating Load (Kg) |
200 |
||
Bucket capacity (m3) |
0.15 |
|||
Max Lifting Force(Kg) |
375 |
|||
Speed (Km/h) |
0~5.5 |
|||
Operating weight(Kg) |
940 |
|||
Fuel tank(L) |
21 |
|||
Hydraulic oil tank(L) |
27 |
|||
Tyre |
16*6-8 |
|||
Max. height (mm) |
2112 |
|||
Dump height(mm) |
1460 |
|||
Overall height (mm) |
1205 |
|||
Overall length with bucket(mm) |
2206 |
|||
Dump distance (mm) |
388 |
|||
Overall Length without bucket(mm) |
1752 |
|||
Bucket width(mm) |
980 |
|||
Overall length to outside of tyre(mm) |
1033 |
|||
Ground clearance(mm) |
90 |
|||
Clearance circuit front (mm) |
1307 |
|||
Dump angle at max height |
30 |
|||
Max attachment rollback when bucket on ground |
25 |
|||
95
